Automatic Plywood Putty Filling Production Line
Automatic Plywood Putty Filling Production Line is a complete automated conveyor system for plywood surface defect repair. It integrates panel feeding, transfer, manual putty filling, turnover and stacking into one continuous workflow.
Made of heavy-duty materials, the line ensures durable and stable long-time operation. Full protection covers key components to enhance safety. Soft-contact surfaces prevent panel scratches. Adjustable conveyor width fits various panel sizes. Custom non-standard layouts are available based on your product specs, output and workshop space.
It helps wood panel manufacturers reduce board damage, save labor cost and achieve consistent production quality.
Based on our modular system engineering, the complete putty repair line integrates the following core functional sections:
- Infeed & Forklift Loading (Ground Roller with Fork Base): Facilitates convenient raw panel bundle loading via forklift.
- Lifting & Pushing Unit (Lifting Table with Roller Conveyor & Pusher): Precise vertical elevation and lateral pushing to feed panels smoothly onto the main processing line.
- Manual Putty Repair Stations (Putty Position by Manual): Ergonomically designed stations with optimized lighting and foot switches for operators to inspect and repair surface defects.
- 180° Panel Turnover Unit (Turnover Machine): Automatically flips the board to enable double-sided defect inspection and putty filling without manual heavy lifting.
- Secondary Repair Zone: Allows secondary side repair and inspection before final transport.
- Outfeed & Automatic Stacking (Belt Conveyor & Stacker): Smooth belt transport delivering finished boards to the auto-stacking system for precise bundle accumulation.
Technical Specifications
| Max. processing board dimension | Length: ≤3200 mm; Width: ≤1640 mm |
| Conveying speed | Up to 9 m/min, frequency‑controlled adjustable |
| Max. stack load capacity | 5000 kg (lifting table) |
| Working conveying height | Approx. 1100 mm |
| Total installed power | Approx. 11.75 kW |
| Pusher mechanical cycle | Approx. 12 seconds per board |
| Pneumatic requirement | Compressed air for turnover machine clamping |
Key Advantages
HALLMARK packaging line manufacturers has always been adhering to the idea of " runs for you" and moving forward with the times. If you have any questions about our end of line packaging products or services, feel free to reach out to customer service team.
